Mirror

Mirror an array of objects in the drawing space.


Default Method: All objects will be mirrored over the line created by Point 3 and Point 4. Text and images cannot be mirrored.

Prompt Data Type Comments
First Sel Point Point First selection point
Second Sel Point Point Second selection point
Mirror Point 1 Point First mirror point
Mirror Point 2 Point Second mirror point

Restrictions: Point3 != Point4
